Electronic functions - kitchen faucet with Touch-function
signs and symbols
- Touch function - hand/object within sensor area
- water fl ows O - LED fl ashes ORANGE
- waterfl ow stops R - LED fl ashes RED
h - hours / min. - minutes / sec. - seconds
function procedure
feedback
signal
information default
setting
range via
Touch
fi rst startup
after installation
1x min. 3 sec. till
remove hand/object from sensor area
- -
wait
R + R 2x/sec., keep out of sensor area
wait till
O 1x
confi rmation, ready for operation
Swivel range setting
the electronic
function
1x app. 2 sec. till
O 1x
extended function mode is active
2x à app. 0,5 sec.
O 1x
R pulsing during active function
2x à app. 0,5 sec.
R fl ashing every second
turn the spout counterclockwise to the edge of
sink
+ / -
45°
+ / -
150°
1x confi rm
O 1x
1. limitation confi rmed
turn the spout clockwise to the edge of sink
1x confi rm
O 1x
2. limitation confirmed
temporary off
«cleaning mode»
activate
1x app. 2 sec. till
O 1x
extended function mode is active
2 min. -
2x à app. 0,5 sec.
O 1x
R pulsing during active function
temporary off
stop
1x app. 2 sec.
O 1x
manual stop
or automatic
O 1x
automatic after preset time
continous run
activate
1x app. 2 sec. till
O 1x
extended function mode is active
2 min. 0,5-20 min.
1x minimum 3 sec.
(max. 5 sec.)
+ O
touch max. 5 sec., water fl ows after releasing
(number of O 1 - 40x shows current setting)
continous run
stop
1x app. 2 sec.
+ O
manual stop
or automatic
+ O
automatic after preset time
follow up
time control
for normal operation
set / programm
1x app. 2 sec. till
O 1x
extended function mode is active
1 sec. 0-10 sec.
1x app. 5 sec. till
R 1x
1x 0 - 10 sec.
keep touched
+ R
R 1x/sec., water fl ows during touching -
releasing defi nes duration
after releasing
O 1x
confi rmation, ready for operation
time of waterfl ow for
continous on
and
purge duration for
line purge feature
set / programm
1x app. 2 sec. till
O 1x
extended function mode is active
2 min.
0,5-20 min.
(in 0,5 min.
steps)
1x minimum 3 sec.
(max. 5 sec.)
+ O
touch max. 5 sec., water fl ows after releasing
(number of O 1 - 40x shows current setting)
1x keep touched till
R 1x - 40x
1x R = 0,5 min. .... 40x R = 20,0 min.
releasing defi nes duration
after releasing
R + O 1x
check / confi rmation of setting by repeating
number of R (1x - 40x) according to setting
line purge feature
activate / deactivate
«automatic fl ush on
set intervall»
1x app. 2 sec. till
O 1x
extended function mode is active
o ff
off
12 h
24 h
48 h
1x app. 25 sec. till
R 1x - 4x
R 1x= off , R 2x= 12h, R 3x= 24h, R 4x= 48h
ignore fl ashes after 5 sec. and 10 sec. - keep
touched till R 1x - 4x aftter app. 25 sec.,
releasing defi nes interval
wait till
O 1x
confi rmation, ready for operation
restart electronics
1x app. 2 sec. till
O 1x
extended function mode is active
- -
2x à app. 0,5 sec.
O 1x
R pulsing during active function
1x app. 5 sec. till
R 4x R 1x/sec.
release and wait till
+ R R 1x/sec., keep out of sensor area
wait till
O 1x
confi rmation, ready for operation
sensor range
set / programm
1x app. 2 sec. till
O 1x
extended function mode is active
6 1-8 steps
2x à app. 0,5 sec.
O 1x
R pulsing
1x app. 15 sec. till
R 1x - 8x
R 1x = min. ...... R 8x = max.
ignore fl ashes R 4x after 5 sec., keep touched
till R 1x - 8x after app. 15 sec., releasing defi nes
sensor range step
release and wait till
+ R R 1x/sec., keep out of sensor area
wait till
O 1x
confi rmation, ready for operation
empty battery
R R 2x/sec. during dedecting hand / object
auto -
