Viking ESFR - User Manual

Other manuals for Viking ESFR

Technical Data111 pages

Questions and Answers

R
Richard KleinJul 26, 2025
What to do if the Viking Irrigation System fails to pump?
- B
  Benjamin VasquezJul 26, 2025
  If your Viking Irrigation System pump isn't pumping, ensure the supply container is full. Also, check and correct the valve position according to the instructions. Verify and correct the pump rotation. If there's insufficient head pressure, raise the supply container. Check the voltage if the pump isn't up to speed. Inspect and clean the Y-Strainer if the suction line is clogged, and check for air in the pump suction line.
W
whitecynthiaAug 1, 2025
Why Viking Irrigation System pump won't operate in automatic mode when the liquid level drops?
- D
  Dylan TurnerAug 2, 2025
  If the pump in your Viking Irrigation System isn't operating in Automatic mode when the liquid level in the tank drops, first verify that there is power at the unit terminal block. Ensure the liquid level in the tank is at the proper height by filling the tank. Check if the magnetic starter overload has tripped; if so, identify and fix the cause of the overload, then press the reset button on the starter. Also, check if the time delay is active and wait 10 minutes for it to time out. If none of these steps work, the pump motor may be defective and require replacement.
R
Robin SingletonAug 7, 2025
How to fix a Viking Irrigation System that will not turn on?
- B
  Brian FlowersAug 7, 2025
  If your Viking Irrigation System unit will not turn on, check the power at both the supply and the unit and correct any issues. Also, check the fuses and replace them if required. Determine what caused the fuse to blow.
N
Nathan FreemanAug 13, 2025
Why does my Viking Irrigation System have excessive power consumption?
- K
  Kevin VangAug 13, 2025
  If the pump in your Viking Irrigation System is consuming excessive power, it may be due to the pump not being fully broken in. Pumps usually draw higher current during the break-in period, and this should resolve itself after several weeks. If the issue persists beyond this period, manually turn the pump to check for mechanical damage. If you feel tight spots after the break-in period, contact Technical Services.
J
Jennifer BallardAug 20, 2025
What to do if Viking Irrigation System pump doesn't operate in automatic mode due to high system pressure?
- A
  Austin WongAug 20, 2025
  Verify that the system pressure switch setting is correct. Note that the CS-1 pressure switch setting must not be adjusted higher. Adjust the CS-1 switch setting lower if approved by the factory.

Summary

System Description

System Design

Hydraulic Calculations

Outlines procedures for hydraulic calculations using Hazen-Williams and Darcy-Weisbach.

Pre-Primed Single Interlocked Preaction System for Cold Storage

System Installation Requirements and Considerations

Tree Configuration - ESFR Cold Storage System

Automatic Pressure Control System

Explains the automatic pressure control system for thermal cycling freezers.

Solution Test Valves

CS-1 Pump

Details the CS-1 Tank and Pump Package for maintaining supervisory pressure.

Propylene Glycol and Water Solution Premix

Riser System

Service Procedures

Outlines general service procedures for the system.

Taking the System Out of Service

Provides instructions for taking the system out of service for maintenance.

Placing the System in Service

Outlines steps to place the system back in service after draining.

Automatic Pressure Control System

Application

System Control Switch

Details the function and operation of the APCS digital pressure control switch.

Pressure Switch Set-Up for Automatic Pressure Control System

Provides step-by-step instructions for setting up the pressure switch.

CS-1 Antifreeze Pump System

Description

Describes the CS-1 Tank and Pump Package for ESFR Cold Storage Systems.

Operating Principle

Explains the operating principle of the CS-1 antifreeze pump system.

CS-1 Control Scheme

Details the control scheme for the CS-1 Tank and Pump System.

Installation

Electrical Connections

Start-Up

Pressure Switch

System Control Switch

Wiring Diagram

Pressure Switch Set-up

Provides detailed instructions for setting up the pressure switch.

Antifreeze Solution 50%

Antifreeze Solution 35%

Description

Typical Properties

Features

System Fill Procedure

Filling The Reservoir Tank

Filling Systems

System and Solution Test and Maintenance

Testing the Solution

Details procedures for testing antifreeze solution concentration and effectiveness.

System Pressure Settings

System Troubleshooting

Viking ESFR Specifications

General

Type	ESFR (Early Suppression Fast Response)
Nominal K-factor Units	gpm/psi^0.5
Thread Size	1 inch NPT
Application	Storage
Installation Orientation	Pendent
Approvals	UL, FM
