TECHNICAL DATA
2” MODEL G-2000 DRY VALVE
RISER ASSEMBLY
Page 10 of 13
The Viking Corporation, 210 N Industrial Park Drive, Hastings MI 49058
Telephone: 269-945-9501 Technical Services: 877-384-5464 Fax: 269-818-1680 Email: techsvcs@vikingcorp.com
Visit the Viking website for the latest edition of this technical data page www.vikinggroupinc.com.
Form No. F_011110 17.04.27 Rev 17.1
Figure 8 - Complete Assembly
Part Number 16149-1 includes:
1 Model G-2000 Dry Valve
1 Model G-2000 Dry Trim
1 10” Section of Schedule 10 Pipe
with Coupling
1 Air Pressure Supervisory Switch
(PS40-2A)
1 Alarm Pressure Switch (PS10-2A)
1 Water Supply Control Valve
Figure 9 - Optional Accessories
Accessories:
08055 Model E-1 Accelerator
14800 Model LD-1 Anti-Column Device
16211 Drain Manifold
