Remove toe grille. Grasp firmly and pull outward to
unclip.
To raise left side door, turn leveler foot
screw clockwise.
Door Alignment (French Door Bottom-Mount)
To raise left side door, turn leveler foot
screw clockwise.
Replace toe grill. Align the toe grille mounting clips
with the lower cabinet slots. Push the toe grille firmly
until it snaps into place.
Complete the Installation
Final Steps
1. Plug into a grounded 3 prong outlet.
2. Return all removable parts to doors and drawer
and food to refrigerator and freezer.
Note:
Allow 24 hours to produce the first batch
of ice. Discard the first three batches of ice
produced. Allow three days to completely fill the
ice container.
16
Remove toe grille. Grasp firmly and pull outward
to unclip.
To raise the front of the refrigerator, turn the leveler foot
screw clockwise.
Note: Having someone push against the
top of the refrigerator takes some weight off the leveler
foot screws.
To lower the front of the refrigerator, turn the leveler foot
screw counterclockwise.
Note: It may take several turns
of the leveler foot screw to adjust the tilt of the
refrigerator.
Replace toe grill. Align the toe grille mounting clips
with the lower cabinet slots. Push the toe grille firmly
until it snaps into place. Check for level.
Leveling
To enhance the appearance and maintain performance, the refrigerator should be level.
To protect property and refrigerator from damage, observe the following:
• Protect vinyl or other flooring with cardboard, rugs, or other protective material.
•
DO NOT use power tools when performing leveling procedure.
Materials Needed
• 1/4” hex head driver
• Carpenter’s level
Note: Complete any required panel installation and/or water supply connection before leveling.
Refrigerator should be in permanent location prior to leveling.
