Viking VCSB423D - CABINET INFORMATION - PROFESSIONAL MODELS; Semi-Flush Installation Details

15
CABINET INFORMATION - PROFESSIONAL MODELS
Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door face protrudes 2-1/2”
(6.4 cm) from the cabinet face. The handle protrudes an additional 2-1/2” (6.7 cm) into the room
DÉTAIL A-A
A-A
AA
AA
42" W 41-1/2" (105.4 cm))
48" W 47-1/2" (120.7 cm)
