Viking VCSB423D - CUSTOM DOOR PANEL DIMENSIONS - FULL OVERLAY MODELS; 42 W. Models Door Panel Dimensions

22
AA AA
BB
AA AA
18 3/16”
(46.2 cm)
22 13/16”
(57.9 cm)
75 1/4”
191.1 cm)
75 1/2”
(191.8 cm)
42” W. MODELS
Non-Dispenser Model
1/8” (0.3 cm) TYP
Four Sides
11//44"" ((00..66 ccmm)) BBaassee PPaanneell
33//44”” ((11..99 ccmm)) FFuullll OOvveerrllaayy PPaanneell
AA
AA
AA
AA
18 3/16”
(46.2 cm)
22 13/16”
(57.9 cm)
1/8” (0.3 cm) TYP
Four Sides
11//44"" ((00..66 ccmm)) BBaassee PPaanneell
33//44”” ((11..99 ccmm)) FFuullll OOvveerrllaayy PPaanneell
Dispenser Cutout Detail
31 5/8”
(80.3 cm)
31 5/8”
(80.3 cm)
10 11/16”
(27.1 cm)
12 3/8”
(31.4 cm)
3 5/32”
(8.0 cm)
1/8” (0.3 cm)
0,3 cm (1/8”)
1/4"(0.6 cm)
3/4"
(1.9 cm)
DDOOOORR
SSEECCTTIIOONN AA--AA
SSHHOOWWNN AASS MMOOUUNNTTEEDD OONN DDOOOORR
NNOO SSCCAALLEE
SSEECCTTIIOONN BB--BB
NNOO SSCCAALLEE
11//44"" ((00..66 ccmm))
BBaassee PPaanneell
BB
Dispenser Model
CUSTOM DOOR PANEL DIMENSIONS - FULL OVERLAY MODELS
33//44”” ((11..99 ccmm))
FFuullll OOvveerrllaayy
PPaanneell
75 1/4”
(191.1 cm)
75 1/2”
(191.8 cm)
