SITE PREPARATIONS AND CONSIDERATIONS
PROFESSIONAL MODEL SIDE-BY-SIDE CABINET OPENING DIMENSIONS
((22)) 22””xx44”” MMoouunnttiinngg bbooaarrdd
((11 11//22”” ((33..88 ccmm)) xx 33 11//22”” ((88..99 ccmm))
NNoottee:: IIff uunniitt iiss iinnssttaalllleedd ddeeeeppeerr tthhaann 2244”” ((6611..00 ccmm)),, tthheenn iinnccrreeaassee tthhee
mmoouunnttiinngg bbooaarrddss bbyy tthhee ssaammee aammoouunntt
33””
((77..66 ccmm))
BB
AA BB
42” W. Models 35” (88.9 cm) 41-1/2” (105.4 cm)
48” W. Models 41” (104.1 cm) 47-1/2” (120.7 cm)
AA
73 3/8”
(186.4 cm)
To Next Page
