Door Removal
1
2
H
O
T
R
E
A
R
F
R
ON
T
H
O
T
R
E
AR
F
R
O
N
T
3
H
O
T
REA
R
F
RO
N
T
HO
T
R
E
A
R
F
R
O
N
T
Open door completely. Fold latches back
until locked in place
Remove hinge screws and hinge
trim
Close door until pins stop door
Door Replacement
1
Carefully realign door on hinges.
Slide in and down
Open door completely.
Fold latches forward until locked in place.
2
3
H
O
T
REA
R
F
RO
N
T
HO
T
R
E
A
R
F
RO
N
T
Remove pins from holes in hinge
4
Lift door up and out.
4
Close door.
5
If the door needs to be adjusted, loosen hinge
trim screws (see step 2). Adjust the screws
located between the door and kickplate using
a 5/32” hex head allen wrench. After
adjustment, tighten hinge trim screws.
CAUTION
TO PREVENT PERSONAL
INJURY
Before removing the doors,
make sure the pins are properly
installed in the hinges. Failure
to do so can result in personal
injury to hands and/or fingers.
