25
41002 - 41005
Setting push button behaviour according to the call button
In this section, you can define the behaviour of the Electronic unit push buttons according to the type of button installed.
Another 3 modes are possible:
• 2 push buttons side-by-side are used to call 1 Indoor Station (default) using a single axial button 41110:
• 2 push buttons side-by-side are used to call 2 Indoor Stations using a single rocker button 41111;
• 4 push buttons are used to call 1 Indoor Station using a double axial button 41112.
N.B.: for the 10 push button module Art. 41010, by selecting the double axial button mode, the last pair of push buttons
is forced to single axial button
Single rocker button
Single axial button
(default)
Double axial button
1
3
5
7
9
11
13
2
4
6
8
10
12
14
1
3
5
7
9
11
13
1
5
9
13
Press repeatedly, until the
LEDs light up as in the
previous section, to select
the function.
Press to confirm
To Next Page
