LED DESCRIPTION
When on, communication is active, when flashing the call is under way
When on, it signals the Bus is busy, when flashing communication was unsuccessful
It turns on when the lock is operated
Situation On (s) Period (s) Duration (s)
Attempt to call with BUS busy 0.1 0.2 2
Call to Indoor Station with ringtone mute 0.1 0.2 5
Call to Indoor Station busy 0.2 0.4 5
The Indoor Station called does not exist 0.1 0.2 1
Secondary ID assignment with parent > 50 0.1 0.2 1
Situation On (s) Period (s)
The chosen configuration has a value that
does not fall within the standard range (it was
changed with SaveProg)
0.1 0.5
Configuration is being reset to the factory value 0.1 0.2
Input for automatic ID assignment to Indoor
Stations pending choice of push button to
start with
0.5 1
The Outdoor Station is verifying whether another
one with the same ID exists
0.25 1
Pending verification whether another Outdoor
Station with the same ID exists
0.25
N.B.: they are offset by 0.25s from
one another, giving the impression of
clockwise rotation
1
Push button remapping
The LED paired with the button to be
remapped remains permanently lit
N.O.
Pending sorting of additional push button
modules
0.5 1
Some of the LEDs illustrated below only come on in certain conditions.
RED LED :
WHITE LEDS:
The situation of remaining in bootloader lasts 10 s from entry.
It exits automatically if the update is not started.
The situation is signalled by the green LED signalling active communication/call under way coming on, and if the electronic unit is powered
by BUS, simultaneously with the lighting of a single white LED, the bottom right one.
