4
RS16.P
EN
DIP-switch functions
DIP Function Status Description
DIP 1 Close immediately OFF Close immediately o
ON Close immediately on:
The engagement and subsequent disengagement of the photocell when closing, while opening or during
the pause time causes the gate to reclose immediately at least 3 s after full opening, regardless of the set
automatic closing time.
DIP 2 Automatic closing OFF Automatic closing o
ON Automatic closing on
DIP 3 Step-step logic OFF 2 steps: step-by-step (term. 51 and radio) with logic in 2 steps (open - close - open)
ON Step-by-step command (term. 51 and radio) with logic in 4 steps (open - stop - close - stop - open - stop)
DIP 4 Apartment block OFF Apartment block o
ON Apartment block on (while the gate is opening, you cannot stop the movement with a radio command or with
inputs 51 (step-by-step) and 52 (pedestrian).
With automatic closing on (DIP-switch 2 = ON) and the gate open, an additional step-by-step command
(terminal 51 or radio command) renews the pause time and if input 51 remains engaged the control panel
suspends the pause count until the input is disengaged (for connecting any coils or a timer).
DIP 5 Slowdown distance OFF Slowdown distance at 10% of the travel
ON Slowdown distance at 20% of the travel
DIP 6 Input 63 function OFF Input 63 congured as photocell (PH)
ON Input 63 congured as safety edge (BAR)
DIP 7 Action speed OFF Action speed high
ON Action speed low
DIP 8 Photo-test OFF Photo-test o
ON Photo-test on
At the start of each action, the control panel checks the operation of the photocells.
It requires specic wiring
LED functions
LED Status Description
PWR OFF Mains power supply not present
ON Mains power supply present
MRX 1 blink Saving a new remote control
2 blinks Saving a remote control already in memory
3 blinks Deleting a remote control
4 blinks Radio memory full
5 blinks Attempt to store a remote control with a dierent code from the one used to set the receiver
10 blinks Complete deletion of the radio memory
51 OFF Step-by-step input (term. 51) not engaged
ON Step-by-step input (term. 51) engaged
52 OFF Pedestrian input (term. 52) not engaged
ON Pedestrian input (term. 52) engaged
61 OFF Stop contact (term. 61) open (engaged)
ON Stop contact (term. 61) closed (not engaged)
62 OFF Photocell engaged when closing (term. 62 open)
ON Photocell not engaged when closing (term. 62 closed)
63 OFF Photocell or safety edge engaged (term. 63 open)
ON Photocell or safety edge not engaged (term. 63 closed)
SW1
OFF Limit switch 1 (corresponding to the right limit switch bracket marked DX) not used
ON Limit switch 1 engaged
SW2
OFF Limit switch 2 (corresponding to the left limit switch bracket marked SX) not used
ON Limit switch 2 engaged
Changing the programmable parameters
The control panel is programmed by default with the following parameters:
- automatic closing: 30 s
- opening direction: to the right
- pedestrian opening position: 1 m
Notes: do not change the wiring for the electric motors. To reverse the opening direction, follow the procedure described below.
