The control panel never needs travel setting as this is automatically measured with each action. When the card is started a full open-close action is
performed to calibrate the travel (it takes place at slower speed as the control panel does not know the exact position of the gate).
To change the default settings, follow the instructions provided below.
NOTES: to change the programmable parameters, the gate must be stationary.
WARNING! THE SAFETY DEVICES ARE DISABLED WHILE THE PROGRAMMABLE PARAMETERS ARE BEING CHANGED.
Changing the automatic closing time
1. While the gate is stationary, press and hold PRG for 2 s; the ashing light comes on and remains steadily lit to indicate that programming is in progress.
The gate closes and reopens.
2. When the gate reaches its opening stop limit, once the desired reclosing time has elapsed (120 s max), press 51 (the gate closes again).
Reversing the opening direction
1. While the gate is stationary and not closed, press and hold PRG for 2 s; the ashing light comes on and remains steadily lit to indicate that program-
ming is in progress. The gate closes.
2. Press MRX (the gate stops).
3. Create a pulse (e.g. Press 51); the gate begins to close.
Changing the pedestrian opening position
1. Have a remote control available with the 2nd radio channel stored.
2. While the gate is closed, press and hold PRG for 2 s; the ashing light comes on and remains steadily lit to indicate that programming is in progress.
The gate opens.
3. Once the desired opening position has been reached, press the button on the remote control stored as the 2nd radio channel.
Note:
If you want to return the control panel to default, perform the following procedure:
1. Disconnect the power to the control panel.
2. Press and hold the PRG button.
3. Reconnect the power to the control panel and wait for the ashing light to come on steady.
4. After 3 sec., release the PRG button. The ashing light will turn o󰀨.
5. The control panel is now set with the default times.
Remote control programming
Note: Remote control programming can only be done with the automatic gate system stationary
Step-by-step programming:
No. Pressing push button
Signal
MRX LED
Description
1 MRX O󰀨 Press and hold down the MRX push button for no more than 7 s
2 MRX+ remote control - With the MRX push button still pressed, press the button of the remote control to be saved
3 - 1 blink Button of the saved remote control (new remote control)
2 blinks Button of the saved remote control (remote control already in memory)
Programming the pedestrian:
No. Pressing push button
Signal
MRX LED
Description
1 MRX+PRG O󰀨 Press and hold down the MRX and PRG push buttons for no more than 7 s
2 MRX+PRG+remote control - With the MRX and PRG push buttons still pressed, press the button of the remote control to be
saved
3 - 1 blink Button of the saved remote control (new remote control)
2 blinks Button of the saved remote control (remote control already in memory)
Deleting a remote control
No. Pressing push button
Signal
MRX LED
Description
1 MRX On steady Press and hold down the MRX push button for at least 7 s until the MRX LED comes on steady
2 MRX+ remote control - With the MRX push button still pressed, press the button of the remote control to be deleted
3 - 3 blinks Deletion successful
Complete deletion of the receiver
No. Pressing push button
MRX LED
indicator
Description
1 MRX Flashing light Press and hold down the MRX push button for at least 14 s until the MRX LED starts ashing
2 - 10 blinks Complete deletion of the receiver
Note:
After deleting all the remote controls, the rst saved remote control congures the control panel to accept only remote controls with a rolling
code or only remote controls with a xed code.
