Vimar Arke User Manual

Viale Vicenza 14
36063 Marostica VI - Italy
www.vimar.com
30804-20594 EN 02 2303
CONNECTIONS
FRONT AND BACK VIEW
L
N
M
30804
30008.x
6 mm
P L N
µ
1
10mm
L
PUSH BUTTON* FOR
SCENARIO CONTROL
* Do not use the signalling unit 00931. The push button can only be used in the case of operation in Bluetooth technology.
A
B
P
A
6 mm
P L N
µ
L
N
D
C
30804
20594.0-19594.0-19594
16494-14594.0-14594
B
A
000
A
A: Button
B: LED
C: DOWN output
D:
UP output
P: Input for wired push button for scenario recalling

Vimar Arke Specifications

General

Type	Switch
Range	Arke
Series	Arke
Brand	Vimar
Material	Thermoplastic
Color	Various
Current	16A
Protection Degree	IP20
Mounting	Flush
