Vimar Eikon Manual

Viale Vicenza 14
36063 Marostica VI - Italy
www.vimar.com
20593 EN 03 2102
Eikon
20593
Arké
19593
Idea
16493
Plana
14593
• In the configuration phase:
LED Meaning
Flashing white
(for max 5 min.)
Zigbee mode active pending
voice assistant
Flashing blue
(for max 2 min.)
Pending receipt of a fw update
Blue permanently lit
Device associated with the
smartphone via Bluetooth
Flashing green during two-position
stable/one-position stable configuration
(for max 5 min.)
Setting in two-position stable
Flashing amber during two-position
stable/one-position stable configuration
(for max 5 min.)
Setting in one-position stable
Amber permanently lit One-position stable time setting
Flashing green 3 times Confirms two-position stable setting
Flashing amber 3 times Confirms one-position stable setting
Flashing green quickly 3 times
Device correctly associated
with the voice assistant
On
(amber for Eikon, blue for Arké, green
for Idea and Plana)
Relay active during normal operation
INSTALLATION RULES.
• Installation must be carried out by qualified persons in compliance with the cur-
rent regulations regarding the installation of electrical equipment in the country
where the products are installed.
• The device must be installed in flush mounting boxes or surface mounting boxes
with Eikon, Arkè, Idea and Plana supports and cover plates.
• Installation must be carried out in mounting boxes with a depth of more than 48 mm.
• The relay output power circuit must be protected against overloads by installing a
device, fuse or automatic 1-way switch, with a rated current not exceeding 16 A.
REGULATORY COMPLIANCE.
RED Directive. RoHS directive.
Standards EN 60669-2-1, EN 301 489-17, EN 300 328, EN 62479, EN 50581.
Vimar SpA declares that the radio equipment complies with Directive 2014/53/EU.
The full text of the EU declaration of conformity is on the product sheet available on
the following website: www.vimar.com
REACH (EU) Regulation no. 1907/2006 – Art.33. The product may contain traces
of lead.
WEEE - User information
The crossed bin symbol on the appliance or on its packaging indicates that the product at the end of its life must be
collected separately from other waste. The user must therefore hand the equipment at the end of its life cycle over to
the appropriate municipal centres for the differentiated collection of electrical and electronic waste. As an alternative to
independent management, you can deliver the equipment you want to dispose of free of charge to the distributor when
purchasing a new appliance of an equivalent type. You can also deliver electronic products to be disposed of that are
smaller than 25 cm for free, with no obligation to purchase, to electronics distributors with a sales area of at least 400
m
2
. Proper sorted waste collection for subsequent recycling, processing and environmentally conscious disposal of the
old equipment helps to prevent any possible negative impact on the environment and human health while promoting the
practice of reusing and/or recycling materials used in manufacture.
