PROGRAMMING INTERPHONE, MONITOR AND DIGITAL
DISTRIBUTOR USER NUMBERS
If the entrance panels are connected in parallel, disconnect those
entry panels on which the ON-OFF jumper is disconnected (or set to
OFF) before programming the user numbers (it is only necessary to
disconnect the panels for programming).
Entrance panels can only be used to program the interphones or
monitors after each entrance panel button has first been programmed.
This done, program the individual units one at a time.
Programming interphones and monitors with internal coder 887B,
887B/1, 6204, 62K4, 6354 from the entrance panel
1) Briefly press the programming button on the interphone or monitor.
2) Press then the door lock release button
until the LED near
the programming button illuminates.
3) If the LED does not illuminate, repeat the above steps from point 1.
4) Remove the handset from the unit and check the audio connection
with the entrance panel.
5) From the entrance panel, key in the number with which you wish to
program the internal unit and route the call by pressing button “C”.
6) Wait for the LED switching off on the interphone for the programming
confirmation.
7) Program the remaining internal units following the same procedure
outlined above.
OPERATING AND PROGRAMMING NOTES FOR INTERPHONES
TYPE 62K4 AND TYPE 887B/1
Call signal
Interphones type 62K4 and type 887B/1 in the standard version emit
the call signal from the interphone loudspeaker. Obviously when the
handset is picked up, the signal is interrupted.
Procedure for the call parameter programming (only for 887B/1).
The interphone generates the call signal and the respective time dwell
internally: the simultaneous push-button pressure on the interphone for
a certain time allows you to accede to the programming menu of the
call parameters (audio frequency: high, medium, low; signal time dwell:
short, medium, prolonged).
To accede to the programming menu of the call parameters follow the
under mentioned steps:
a) high frequency and short time dwell,
b) high frequency and medium time dwell,
c) high frequency and prolonged time dwell;
d) medium frequency and short time dwell,
e) medium frequency and medium time dwell,
f) medium frequency and prolonged time dwell;
g) low frequency and short time dwell,
h) low frequency and medium time dwell,
i) low frequency and prolonged time dwell;
Ringtone volume adjustment option (only for interphone 62K4)
- jumper ON = ringtone volume high
- jumper OFF = ringtone volume low
Procedure for programming call parameters on interphone 62K4
2) Then press the
button until the red LED lights up, keeping
it pressed for a further 5 seconds until the red LED changes from a
4) The interphone starts to play the preset melody. By repeatedly
pressing the lock button “C” you can cycle through 9 melodies of
5) Once you have selected the desired melody, wait for the red LED
has been stored.
Procedure for programming call parameters for interphone 887B/1
To access the call parameter programming menu:
1) Simultaneously press and hold down the two interphone buttons for
(high frequency and short duration);
2) By repeatedly pressing the F1 auxiliary function button (2nd button)
-
lected call type;
4) If neither button is pressed for 20 seconds, the interphone will exit
call parameter programming mode and return to normal operating
status.
Programming digital distributors 949B from the entrance panel
LEDs on the distributor illuminates.
3) If the LED does not illuminate, repeat the above steps from point 1.
4) Remove the handset from the interphone or monitor connected to
terminals A1 and A3 of the digital distributor in question and check
the audio connection with the entrance panel.
5) From the entrance panel or switchboard, key in the number with
which you wish to program the internal unit and route the call by
pressing button “C”.
7) To program the remaining three internal units (interphones or moni-
tors) connected to the distributor in question, press button PS1 again
and hold button PS2 pressed down until the corresponding LED illu
-
minates on the distributor (second, third or fourth LED).
8) The LEDS illuminate to indicate which internal unit is currently being
programmed as illustrated in the table below, whereby:
LED 1 ¬ ® Terminals A1 and A3
LED 2 ¬ ® Terminals B1 and B3
LED 3 ¬ ® Terminals C1 and C3
LED 4 ¬ ® Terminals D1 and D3
9) Program the remaining internal units following the same procedure
outlined above.
PROGRAMMING INTERPHONES, MONITORS AND DIGITAL DIS-
TRIBUTORS FROM SWITCHBOARD 945B AND 955
To program interphone and monitor user numbers with the switchboard,
proceed as follows:
- Set the switchboard in “INTERNAL” mode.
- Lift the switchboard handset and press button
so that the indi-
cator lamp in key illuminates.
- Without replacing the handset on the switchboard, program the in-
terphone, monitor or distributor.
Programming interphones and monitors with internal coder 887B,
887B/1, 6204, 62K4, 6354
2) Press then the door lock release button
until the LED near
the programming button illuminates.
3) If the LED does not illuminate, repeat the above steps from point 1.
4) Remove the handset from the unit and check the audio connection
8
EN
