Vimar ELVOX 945B

22
VERSION 3
External chime connection for call repeater on the switchboard.
Switchboard
Art. 945B
BASIC DIAGRAM VERSIONS
Relay
Art. 0170/001
External
chime
DIAGRAM SYMBOLS
A.C. buzzer
A.C. bell
Electric lock
Lamp
Push-button
Switch
Loudspeaker
Amplified microphone
Receiver
A.C. supply from mains
Ground
Coaxial cable grip
