Vimar ELVOX EKKO 350A User Manual

8
EKKO
9
8
YES !
Make sure to tighten
the bolt that fastens the
operator to the bracket
allowing it to rotate freely.
NO !
The operator height
must not change in
the various movement
steps.
S1
Z
Y
X
S2
Z Y X
S3
Z Y X
45
Amax
B
C
D
E
L
α
B
A
C
D
ANT
Leaf attachment
EKKO 350A
ANT 500
Leaf attachment
EKKO 500A
COL
Column attachment
EN
Observe the height 45 and make sure that the operator is horizontal
FIXING THE OPERATOR ATTACHMENT TO THE GATE
(to see the TABLES of the measures).
Before inserting the pin into the gate attachment, grease thoroughly.
Weld the base at the right height (Fig. 8).
Fix the EKKO 350A / EKKO 500A and try several times to open and to close
the gate, controlling that the operator does not touch the moving gate

Vimar ELVOX EKKO 350A Specifications

General

Brand	Vimar
Model	ELVOX EKKO 350A
Category	Controller
Language	English
