Vimar ELVOX Quick Guide

3
TAB: 40507
EN
Description
Wall-mount handsfree video entryphone for Due Fili Plus system,
integrated Wi-Fi for call repetition on smartphone with dedicated
app, with 7" touch-screen colour LCD display, capacitive keypad
for video entryphone functions and intercom calls, video voicemail,
induction loop for hearing aids, complete with bracket for fixing in
round or rectangular mounting box.
Desktop installation is possible with the desktop base accessory
40195 (sold separately).
Read the instructions before installation
and/or use.
Technical characteristics
• Wall-mounted, with metal bracket, in box: circular 2M (Vimar
V71701), 3M (Vimar V71303, V71703) horizontal and vertical,
4+4M (Vimar V71318, V71718) and square, British standard.
• 7" LCD 16:9 display, resolution 800x480 pixels
• Minimum video signal level on the bus for reception: -20 dBm
• Capacitive touch keypad with backlit symbols.
• Powered from BUS terminals 1, 2 - nominal voltage 28Vdc
• Power consumption:
- in standby: 120 mA
- maximum current: 400 mA
• Frequency bands: 802.11 b, g, n, 2.4 GHz
• Frequency range: 2412 - 2472 MHz
• RF Output power: < 100 mW (20 dBm)
• Ambient class: Class A1 (indoor use)
• IP30 protection rating
• Operating temperature: -5°C to +40°C (indoor use)
• Operating ambient humidity 10 - 80% (non-condensing)
• Electronic ringer with 10 different melodies.
• Input for landing call.
• Input for additional power supply: only code Elvox 6923, 28Vdc
0.5A INT
• Dimensions: 165.8 x 184 x 24.2 mm
• DIP switch for line termination impedance.
Main functions
• Receiving video calls from speech unit.
• Speech unit self-starting.
• Speech unit lock opening.
• Intercom audio calls.
• Activating system actuations (stair light, auxiliary functions).
• System contacts list and favourites menu for quick access.
• Configurable video voicemail.
• Multiple ringtones, configurable from those available in the
device.
• Adjust audio and video call settings.
• Input for landing bell.
• Mounting frame for CCTV integration.
• Mounting frame for remote call service on smartphone/tablet
via WiFi connectivity.
Audio frequency function for hearing aids
The instructions manual can be downloaded from the
website www.vimar.com
The video entryphone can be used by people wearing hearing
aids.
For correct functioning of the hearing aid, please refer to its
instruction manual. Any metal objects or electronic equipment in
the vicinity may a󰀨ect the quality of the sound received by the
hearing aid.
Maintenance
Clean using a soft cloth. Do not pour water onto the appliance and
do not use any type of chemical product.
Cleaning must be carried out either with the apparatus powered
o󰀨 (= disconnected from the bus) or after activating the keypad
cleaning procedure (see the relative paragraph in the User
Manual).
Warnings for the user
Do not open or tamper with the appliance.
In the event of faults, contact specialized personnel.
• Installation should be carried out by qualified personnel in
compliance with the current regulations regarding the installation
of electrical equipment in the country where the products are
installed.
• Install the device at a height of no more than 2 m.
Conformity
RED directive
Standards EN 301 489-17, EN 300 328, EN 62311, EN 60065,
EN 60118-4, EN 61000-6-1, EN 61000-6-3.
REACH (EU) Regulation no. 1907/2006 – Art.33. The product
may contain traces of lead.
Vimar SpA declares that the radio equipment complies with Directive
2014/53/EU. The full text of the EU declaration of conformity is
on the product sheet available at the following Internet address:
www.vimar.com.
WEEE - Information for users
If the crossed-out bin symbol appears on the equipment or
packaging, this means the product must not be included
with other general waste at the end of its working life. The
user must take the worn product to a sorted waste center, or return
it to the retailer when purchasing a new one. Products for disposal
can be consigned free of charge (without any new purchase
obligation) to retailers with a sales area of at least 400m
2
, if they
measure less than 25cm. An e󰀩cient sorted waste collection for
the environmentally friendly disposal of the used device, or its
subsequent recycling, helps avoid the potential negative e󰀨ects on
the environment and people’s health, and encourages the re-use
and/or recycling of the construction materials.
