Man-1131_Hydrosense_HSCP_01 Page 13 of 18
Table 8 – Configuration codes
CODE FUNCTION COMMENTS
00 SOUNDER DELAY TIME = 30 SECONDS
01 SOUNDER DELAY TIME = 1 MINUTE
02 SOUNDER DELAY TIME = 2 MINUTES
03 SOUNDER DELAY TIME = 3 MINUTES
04 SOUNDER DELAY TIME = 4 MINUTES
05 SOUNDER DELAY TIME = 5 MINUTES
06 SOUNDER DELAY TIME = 6 MINUTES
07 SOUNDER DELAY TIME = 7 MINUTES
08 SOUNDER DELAY TIME = 8 MINUTES
09 SOUNDER DELAY TIME = 9 MINUTES
Sets the time delay before sounders operate in combination with
configuration codes 31 to 48 and access level 2 function AD.
10 COMMON ALARM MODE (default) All sounders operate upon any alarm condition
11 TWO-STAGE ALARM MODE Continuous sounders in activated zone, pulsing elsewhere
12 ZONED ALARM MODE Only sounders connected to zone in alarm operate
21* DISABLE ALARM BUZZER Buzzer will not operate on alarm condition
22* DISABLE FAULT OUTPUT Fault relay will not operate except upon total power failure
23 DISABLE EARTH FAULT MONITORING Connection of alarm wiring will not announce a fault
24 PULSED REMOTE CONTROL OUTPUT Aux 24V supply pulses 1 sec on/1 sec off
25 ENABLE SOUNDERS ON DETECTION CIRCUITS Set if using sounder extension boards
26 DISABLE ALARM OUTPUT Alarm relay will not operate upon any alarm
27 REMOVE AUX 24 UPON PANEL RESET 24V supply switches off for about 5 seconds when panel is reset
28 NOT USED
29 DO NOT RE-SOUND ALARMS FROM ANOTHER ZONE Silenced sounders will not re-sound upon further zone
activations
31 ZONE 1 ALARM FROM DETECTOR DELAYED
32 ZONE 2 ALARM FROM DETECTOR DELAYED
33 ZONE 3 ALARM FROM DETECTOR DELAYED
34 ZONE 4 ALARM FROM DETECTOR DELAYED
35 ZONE 5 ALARM FROM DETECTOR DELAYED
36 ZONE 6 ALARM FROM DETECTOR DELAYED
37 ZONE 7 ALARM FROM DETECTOR DELAYED
38 ZONE 8 ALARM FROM DETECTOR DELAYED
Sounder outputs will be delayed by time set at options
0-9 when selected zone(s) triggered by detector only.
Note: Access level 2 function Ad must be set for this to take
effect.
51 COINCIDENCE ZONE 1
52 COINCIDENCE ZONE 2
53 COINCIDENCE ZONE 3
54 COINCIDENCE ZONE 4
55 COINCIDENCE ZONE 5
56 COINCIDENCE ZONE 6
57 COINCIDENCE ZONE 7
58 COINCIDENCE ZONE 8
Zone contributes to ancillary board coincidence O/P. Any
number of zones can be selected to contribute.
CODE FUNCTION COMMENTS
71* ZONE 1 SHORT CIRCUIT INDICATES ALARM
72* ZONE 2 SHORT CIRCUIT INDICATES ALARM
73* ZONE 3 SHORT CIRCUIT INDICATES ALARM
74* ZONE 4 SHORT CIRCUIT INDICATES ALARM
75* ZONE 5 SHORT CIRCUIT INDICATES ALARM
76* ZONE 6 SHORT CIRCUIT INDICATES ALARM
77* ZONE 7 SHORT CIRCUIT INDICATES ALARM
78* ZONE 8 SHORT CIRCUIT INDICATES ALARM
Changes the trigger threshold of the
zone so that the control panel can be
used on older systems that had no short
circuit monitoring.
81* ZONE 1 NON-LATCHING
82* ZONE 2 NON-LATCHING
83* ZONE 3 NON-LATCHING
84* ZONE 4 NON-LATCHING
85* ZONE 5 NON-LATCHING
86* ZONE 6 NON-LATCHING
87* ZONE 7 NON-LATCHING
88* ZONE 8 NON-LATCHING
Renders the zone self-resetting so that
it can be used to receive signals from
other systems and will reset when the
input is removed.
Note: It can take up to 20 seconds for zone to reset itself when
sounders are operating
91 ZONE 1 DOES NOT SOUND ALARMS
92 ZONE 2 DOES NOT SOUND ALARMS
93 ZONE 3 DOES NOT SOUND ALARMS
94 ZONE 4 DOES NOT SOUND ALARMS
95 ZONE 5 DOES NOT SOUND ALARMS
96 ZONE 6 DOES NOT SOUND ALARMS
97 ZONE 7 DOES NOT SOUND ALARMS
98 ZONE 8 DOES NOT SOUND ALARMS
Prevents the zone from operating the two common sounder
outputs.
