ASSEBMLY STEPS
STEP 24
31
1
3
10
13
E
E
(2)
J-1
J-2
(1)
J-1
Push the upper snap to the front,
and then install the upper drawer
Pull Drawer Slide(J-1) out first, and the ball along with it to the
front; Keep the drawer level and insert the drawer with the slides
aligned.Note! Failure to level may result in damage to the slides
!
To Next Page
