ASSEBMLY STEPS
STEP 25
32
1
3
10
10
16
E
E
(2)
J-1
J-2
(1)
J-1
Pull Drawer Slide(J-1) out first, and the ball along with it to the
front; Keep the drawer level and insert the drawer with the slides
aligned.Note! Failure to level may result in damage to the slides
!
Push the lower snap to the front,
and then install the lower drawer
To Next Page
