4.4 SENSOR RESISTANCE CHARACTERISTICS TABLE
No. MEASURED TEMPERATURE
(°C)
RESISTANCE OF SENSOR
(kΩ)
1
-30 116.55
2
-28 104.97
3
-26 94.67
4
-24 85.49
5
-22 77.30
6
-20 69.99
7
-18 63.44
8
-16 57.58
9
-14 53.32
10
-12 47.60
11
-10 43.35
12
-8 39.53
13
-6 36.08
14
-4 32.97
15
-2 30.16
16
0 27.62
17
2 25.32
18
4 23.24
19
6 21.35
20
8 19.63
21
10 18.07
22
12 16.65
23
14 15.35
24
16 14.17
25
18 13.10
26
20 12.11
27
22 11.21
28
24 10.39
29
25 10.00
30
26 9.63
31
28 8.94
32
30 8.30
33
32 7.72
34
34 7.18
35
36 6.69
36
38 6.23
37
40 5.81
38
42 5.42
39
44 5.06
40
46 4.73
41
48 4.43
42
50 4.15
• The tolerance of sensor resistance is ±5%
• Be sure to measure the sensor resistance after keeping the sensor more than 3 minutes at a
measuring temperature. (It needs delay due to sensor speed.)
