Model No.
VC33S VC33D
Type
Built-in or Free Standing Installation
Capacity
Total Storage Volume - L 95 92
Wine Storage Bottles Zone One 33 12
Zone Two N.A 16
Zone Three N.A N.A
Performance & Features
Ambient Temp. Range °C/°F 16 ~ 38 / 60 ~100 0 ~ 38 / 32 ~100
Setting Temp. Range °C/°F 5 ~ 22 / 40 ~ 72 5 ~ 22 / 40 ~ 72
Power Source V/Hz 115/60 220-240/50 115/60 220-240/50
Energy Consumption KWh/24h 0.53 0.60 0.64 0.66
Rated Input W 100 85 100 85
Rated Current A 1.0 0.6 1.0 0.6
Heater W N.A 80
Noise Level dB(A) 45 45
Defrost Type Automatic Automatic
Temp. Control Electronic Electronic
Blowing Agent Cyclopentane Cyclopentane
Refrigerating System
Cooling System Air Forced Convection
Type
Air Forced Convection
Type
Compressor Model No. JK1111HY D53CY JK1111HY D53CY
Type Hermetic Type Hermetic Type
LRA 12.5 8.1 12.5 8.1
RLA 0.80 0.55 0.80 0.55
Overload Protector 4TM232VH
BYY
B35—120 4TM232V
HBYY
B35—120
PTC Starter
QP2-4.7/B
3
QP2—15
QP2-4.7/B
3
QP2—15
Oil ISO8/ISO1
0 175ml
S8P 150ml
(MO)
ISO8/ISO
10 175ml
S8P 150ml
(MO)
Condenser Fan Motor Model No.
TD1225LB/YM1212PTB3 TD1225LB/YM1212PTB
3
Rating 12 V DC, 0.18 A/0.11A 12 V DC, 0.18 A/0.11A
Evaporator Fan Motor Model No.
TD8020LS/YM1208PKS3 TD8020LS/YM1208PKS
3
Rating
12 V DC, 0.08
Expansion device Capillary (Ø0.7x1200mm) Capillary
(Ø0.7x1200mm)
Refrigerant / Charged Volume R600a/0.81
Oz
R600a/18g R600a/0.8
1Oz
R600a/18g
Dimensions & Weights
Net Dimensions Width – mm / in 375/14¾" 375/14¾"
Height – mm / in 864/34" 864/34"
Depth – mm / in 615/24¼" 615/24¼"
Packing Dimensions Width – mm / in 415/16⅜" 415/16⅜"
Height – mm / in 910/35⅞" 910/35⅞"
Depth – mm / in 628/24¾" 628/24¾"
Weight Net / Gross – KG / Lb 32/70.5 / 35/77.0 32/70.5 / 35/77.0
* Specifications are subject to change without prior notice.
