Model No.
VC54S VC54D
Type
Built-in or Free Standing Installation
Capacity
Total Storage Volume - L 145 135
Wine Storage Bottles Zone One 54 16
Zone Two N.A 38
Zone Three N.A N.A
Performance & Features
Ambient Temp. Range °C/°F 0 ~ 38 / 32 ~100 0 ~ 38 / 32 ~100
Setting Temp. Range °C/°F 5 ~ 22 / 40 ~ 72 5 ~ 22 / 40 ~ 72
Power Source V/Hz 115/60 220-240/50 115/60 220-240/50
Energy Consumption KWh/24h 0.64 0.54 0.64 0.54
Rated Input W 100 100 100 100
Rated Current A 1.0 1.2 1.0 1.2
Heater W 120 120
Noise Level dB(A) 45 45
Defrost Type Automatic Automatic
Temp. Control Electronic Electronic
Blowing Agent Cyclopentane Cyclopentane
Refrigerating System
Cooling System Air Forced Convection
Type
Air Forced Convection
Type
Compressor Model No. JK1111HY JM1110Y JK1111HY JM1110Y
Type Hermetic Type Hermetic Type
LRA 12.5 8.7 12.5 8.7
RLA 0.80 0.65 0.80 0.65
Overload Protector 4TM232VH
BYY
B40-120/B 4TM232V
HBYY
B40-120/B
PTC Starter
QP2-4.7/B
3
QP2-12/B
QP2-4.7/B
3
QP2-12/B
Oil ISO8/ISO1
0 175ml
ISO8/ISO10
175ml
ISO8/ISO
10 175ml
ISO8/ISO1
0 175ml
Condenser Fan Motor Model No.
TD1225LB/YM1212PTB3 TD1225LB/YM1212PTB
3
Rating 12 V DC, 0.18 A/0.11A 12 V DC, 0.18 A/0.11A
Evaporator Fan Motor Model No.
TD1225LS/YM1212PTS3 TD1225LS/YM1212PTS
3
Rating
12 V DC, 0.18 A/0.11
Expansion device Capillary (Ø0.7x1600mm) Capillary
(Ø0.7x1600mm)
Refrigerant / Charged Volume R600a/0.99
Oz
R600a/28g R600a/0.9
9Oz
R600a/28g
Dimensions & Weights
Net Dimensions Width – mm / in 595/23½" 595/23½"
Height – mm / in 820/32¼" 820/32¼"
Depth – mm / in 615/24¼" 615/24¼"
Packing Dimensions Width – mm / in 660/26.0" 660/26.0"
Height – mm / in 880/34⅝" 880/34⅝"
Depth – mm / in 628/24¾" 628/24¾"
Weight Net / Gross – KG / Lb 43/95 / 47/104 43/95 / 47/104
* Specifications are subject to change without prior notice.
