User's Manual
Arctic GPRS Gateway
Firmware Version 5.0.7 15 Document Version 1.6
Figure 6. Back Panel
1. FME connector for an antenna.
2. SIM Card slot.
Note!
It is recommended NOT to insert or remove the SIM card while the GPRS
module is in operation. The SIM card contents may become corrupted if the
card is removed while the GPRS module is writing data to it.
2.3 Side Panel Description
The side panel of the device contains ten LEDs which are used to indicate
the status of the Arctic and only five of them are connected. The LEDs are
numbered from 1 to 10 starting from the rear panel side. A detailed description
of each LED is listed below:
Figure 7. LED Description
