VIPA SM 231 - Technical Data

Chapter 5 238-2BC00 - Combination module Manual VIPA System 200V
5-40 HB97E - SM-AIO - Rev. 12/32
Technical Data
Order number 238-2BC00
Type SM 238C, Digital In-/Output,
Counter, Analog In-/Output
Current consumption/power loss
Current consumption from backplane bus 280 mA
Power loss 5.5 W
Technical data digital inputs
Number of inputs 16
Cable length, shielded 1000 m
Cable length, unshielded 600 m
Rated load voltage -
Current consumption from load voltage L+ (without
load)
-
Rated value DC 20.4...28.8 V
Input voltage for signal "0" DC 0...5 V
Input voltage for signal "1" DC 15...28.8 V
Input voltage hysteresis -
Frequency range -
Input resistance -
Input current for signal "1" 7 mA
Connection of Two-Wire-BEROs possible
9
Max. permissible BERO quiescent current 1.5 mA
Input delay of "0" to "1" 3 ms
Input delay of "1" to "0" 3 ms
Number of simultaneously utilizable inputs
horizontal configuration
-
Number of simultaneously utilizable inputs vertical
configuration
-
Input characteristic curve IEC 61131, type 1
Initial data size 16 Byte
Technical data digital outputs
Number of outputs 4
Cable length, shielded 1000 m
Cable length, unshielded 600 m
Rated load voltage DC 20.4...28.8 V
Reverse polarity protection of rated load voltage -
Current consumption from load voltage L+ (without
load)
20 mA
Total current per group, horizontal configuration,
40°C
-
Total current per group, horizontal configuration,
60°C
-
Total current per group, vertical configuration -
Output voltage signal "1" at min. current -
Output voltage signal "1" at max. current L+ (-0.8 V)
Output current at signal "1", rated value 1 A
Output current, permitted range to 40°C -
Output current, permitted range to 60°C -
Output current at signal "0" max. (residual current) -
Output delay of "0" to "1" 150 µs
Output delay of "1" to "0" 100 µs
Minimum load current -
Lamp load 5 W
Parallel switchin
g
of out
p
uts for redundant control not possible
