OPERATING AND MAINTENANCE INSTRUCTIONS
196cc 4-Cycle Engine
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-56
SPECIFICATIONS
Displacement/Stroke 196 cc; 4-stroke
Ignition Type Electronic ignition
Cooling System Forced air cooling
Idling Carburetor Adjust 1700 +/- 150 RPM
Valve Clearance Cold engine-Intake: 0.15 +/- 0.02 mm;
Exhaust: 0.20 +/- 0.02 mm
Maximum Torque 11-N.M./2500 RPM
Bore and Stroke 68 x 54 mm
Spark Plug Type BP7ES, BPR7ES (NGK), or ~ 0.7 mm gap Torch F7TC
Gasoline Type Unleaded
Gasoline Tank Capacity 0.95 gallon (3.6 liters)
Drive Shaft Type Horizontal, 3/4” straight, (3/16”) keyed shaft with ball
bearings. Direction: counterclockwise (facing shaft);
Length: 2-1/4”; Central thread: 5/16”-24
Start Type Recoil
Speed 3600 RPM
Oil Capacity and Type ~0.63 quart (0.6 liters); SAE 30 (in freezing weather
use 5W30)
Weight 33.8 lbs.
Overall Dimensions 12-3/4” L x 14” W x 10-1/4” H
