Viper 340cc 4-Cycle Engine - Illustrated Parts Breakdown

Operator's Manual
Viper® 340cc 4-Cycle Engine
18
Check for parts online at www.ardisam.com or call 800-345-6007 M-F 8-5
ITEM # PART # DESCRIPTION QT Y.
1 21423 KIT BLOWER HOUSING 1
2 21415 KIT FLYWHEEL IMPELLER STARTER 1
3 21425 KIT ASSEMBLY DIPSTICK 1
4 21421 KIT FUEL LINE AND CONNECTOR FILTER 1
5 21424 KIT AIR CLEANER 1
6 21581 KIT AIR CLEANER REPLACEMENT 1
7 21413 KIT IGNITION COIL AND HARDWARE 1
8 21428 KIT MUFFLER 1
9 21470 GASKET MUFFLER EXHAUST FLANGE 1
10 21472 GASKET HEAD EXHAUST FLANGE 1
11 21482 KIT ASSEMBLY PLUG ENGINE OIL 1
12 21231 SEAL CRANK ENGINE RV340 2
13 21444 KIT THROTTLE ASSEMBLY 1
14 21277 SPARK PLUG RV340 1
15 21422 KIT CYLINDER HEAD COVER 1
16 21226 KIT CARBURETOR 1
17 21245 GASKET INTAKE TO CARB ENGINE RV340 1
18 21469 GASKET INSULATOR CARBURETOR 1
19 21297 FLANGE CARBURETOR RV340 1
20 21244 GASKET CARB TO ENGINE RV340 1
21 21370 STARTER 340CC RV340 1
NOTE: Service kits contain multiple parts shown within outlined boxes.
ILLUSTRATED PARTS BREAKDOWN
340cc Engine Main PARTS Explosion
