Viper TR-3 - Page 5

MODEL: TR-3
COMPONENT
DESCRIPTION
COMPONENT
MANUFACTURER
MFR’S PART NO. QUANTITY
1
Cover
Viper Gate Systems
tr3cov1 1
2
Set Phillips screw
Viper Gate Systems
tr3sps2 1
3
½ h.p. Motor
Viper Gate Systems
tr3mot3 1
4
Limit magnets
Viper Gate Systems
tr3lm4 2
5
Control board
Viper Gate Systems
tr3c/b5 1
6
Capacitor
Viper Gate Systems
tr3cap6 1
7
Gear racks 2.3 ft.
Viper Gate Systems
tr3gr7 5
8
Plastic clip
Viper Gate Systems
tr3pc8 4
9
Base plate for receiver/
limit switch sensor
Viper Gate Systems
tr3bp9 1
10
Base plate for control board
Viper Gate Systems
tr3bp10 1
11
Plastic clip
Viper Gate Systems
tr3pc11 4
12
Receiver
Viper Gate Systems
tr3rec12 1
13
Large bracket for magnet (open limit)
Viper Gate Systems
tr3lbol13 1
14
Limit switch sensor
Viper Gate Systems
tr3ls14 1
15
19 tooth Sprocket
Viper Gate Systems
tr319spr15 1
16
C-Clamp
Viper Gate Systems
tr3ccl16 1
17
Motor housing
Viper Gate Systems
tr3mh17 1
18
Small bracket for magnet (close limit)
Viper Gate Systems
tr3sbcl18 1
19
Mounting base
Viper Gate Systems
tr3mb19 1
20
Manual release keys
Viper Gate Systems
tr3keys20 2
