VirtuaPin Plunger Kit - Wiring Guide; J1 (10-Pin) Connector Mapping; J2 (8-Pin) Connector Mapping; USB and Calibration


Wiring
(Pins are numbered le to right)

Plug the cable into the connector pictured above in Diagram2, and then into your PC. The controller will auto‐
macally be detected, and the drivers installed.
The accelerometer (nudging) is auto‐calibrated on power on. To calibrate the plunger, simply pull it all the way
back, hold for 2 seconds, and release.
J1(10‐Pin)Connector
PIN
1
2
3
4
5
6
7
8
9
10
BUTTON
Digital Plunger
Right Flipper
Not Used
Common/Ground
Right Magnasave
Change Camera*
Toggle HUD*
Look at Backbox*
Pause
Exit Table
Joy
1
2
—
—
3
4
5
6
7
8
J2(8‐Pin)Connector
PIN
1
2
3
4
5
6
7
8

BUTTON
Start Game
Le Flipper
Le Magnasave
Insert Coin 1
Insert Coin 2
Test*
Service*
Ground
Joy
9
10
11
12
13
14
15
—
COLOR
Green
Red
—
Black
White
Purple
Orange
Blue
Gray
Yellow
COLOR
Green
Red
White
Yellow
Purple
Brown
Blue
Black
*UsedwithFuturePinball
USBandCalibraon
90DayLimitedManufacturer’sWarranty
