EN
Virtufit Premium Trampoline with Safety Net
13
ASSEMBLY INSTRUCTIONS
STEP 5
• Connect the bottom pole tube (K) to the upper pole tube (L).
• Align the hole in the bottom pole tube with the slot in the top tube, screw one of small screws (R)
through the slot in the top tube and into the hole in the bottom tube using the screwdriver (P). Slide
the PVC sleeves (T) onto the assembled enclosure poles.
• Fixing on bottom pole tube (K) onto trampoline legs with fork screw (N) and 9 shape screw (O) as
shown in diagram, secure with nut by Spanner (P). Be sure to have someone help you hold the tube
frame steady when you do this. Ensure all nuts and bolts are securely tight.
