Virtufit Premium Trampoline with Safety Net
17
ASSEMBLY INSTRUCTIONS
LADDER
• Place the two frame legs (2) in a free space. Then place one of the ladder steps (1) on the bottom of
each frame leg. Then slide the step up to the top bolt holes of the legs and the steps. NOTE! Make
sure the diamond pattern of the stairs is facing up is targeted.
• Insert two Bolts (4) through the Ladder Step (1) and Frame Legs (2). Then, tighten a Nut (3) to the
back of each Bolt with a Screwdriver (Q).
• Repeat steps 1 and 2 to assemble the second ladder step.
• Place the lower frame base (5) on to the ladder frame legs (2), making sure that the screw holes are
aligned.
• Insert two short screws (6) through the Lower Frame base (5) and Frame Legs (2). Then, tighten each
Short Screw with a Screwdriver (Q).
• Test the steps to ensure they are properly attached.
• Find the net opening of your safety net. Lift your protective edge and transfer the hooks from the
ladder the curved frame of the trampoline. Pull out the ladder at the base of the trampoline to make
sure it hits the ground as far away from the trampoline frame as possible.
# DESCRIPTION QTY
1 Ladder Step 2
2 Frame Leg 2
3 Nut 4
4 Bolt 4
5 Lower Frame Base 1
6 Short Screw 2
