PARTS LIST
# Description QTY
01 Main frame 1
02 Knob M10*25 2
03 End cap 2
04 Foam grip 2
05 Handlebar 1
06 Computer 1
07 Tension control 1
08 Flat washer D10x2.0xΦ20 4
09 Nylon nut M10 2
10 Flat washer D13x2.0xΦ26 2
11 Pedal 2
12 Bolt M12x155x16 2
13 Saddle 1
14 Bolt M10*100 1
15 Knob M16x1.5 1
16 Nylon nut M8 4
17 Flat washer D8x1.5xΦ16 8
18 Slide rest 1
19 Hexagon bolt M8x30xL10 4
20 Cross pan bolt 2
21 Flat washer d6x1.2xΦ16 2
22 Slide way 1
23 Tension Belt 1
24 Limit valves 4
25 Hexagon bolt M10*95 1
26 Cross pan bolt M6*12 4
27 Cross pan bolt ST4.2*8 4
28 Protect guard 1
29 Stand rail 1
30 Carriage bolt M8*73 2
31 Arc washer d8x2xΦ25xR30.5 2
# Description QTY
32 Cap nut M8 2
33 Front bottom tube 1
34 End cap 2
35 Flat washer 1
36 Sensor splice 1
37 Cross pan bolt ST3x10 2
38 Rubber pad 1
39 Magnet 1
40 Limit valves axis 2
41 Hexagon bolt M8x20 4
42 Roller 4
43 Roller spacer bush 4
44 Spring washer D8 4
45 Connection strap 1
46 Sensor wire 1
47 Sensor 1
48 Rotary plate 1
49 Bearing 6000 4
50 Plug 1
51 Bushing 1
52 Flywheel 1
53 Magnet board 1
54 Screw ST4.2X18 4
55 Hexagon bolt M6*15 4
56 Arc washer D6 4
57 Flat washer D6x1.0xΦ12 4
58 Pulley 2
59 Screw ST4.2x18 10
60 L/R chain cover 1/1
61 Bolt M10*1.0 1
62 Hexagon bolt M10*1.0 3
