12.2 Cleaning the pressure roller A (Fig. 19)
Remove screws D (Fig. 19) with the help of the service key E,
unscrew knob C and remove cover B (Fig. 19) A (Fig. 20).
Press support A (Fig. 21) with the right hand while the left
hand extracts shaft B (Fig. 21) and roller C. Clean the roller
and replace it following these steps in reverse.
(Figure 19)
(Figure 20)
(Figure 21)
E
D
DB
C
A
A
B
C
A
