3-1
SECTION 3. Operation
3.1 DISPLAY OPERATION
Upon power up of both units, remote digital displays provide digit-for-digit display duplication of the host
device display readout. Display updates, occurring approximately ten times a second, include weight,
rate*, level, and alarm status data. If a fixed display format is selected, the remote unit can display one
mode such as net or rate* while the host device displays a different mode such as gross.
*Rate not available with LCp-100 based systems
3.2 REMOTE CONTROL FUNCTIONS
When enabled, tare, zero, and gross-net-rate* selection functions can be performed using the remote display
front panel keys (Figure 4-1). Pressing a key causes the host to respond as if its own key had been pressed. The
only exception is the PRINT/COM key, which has no function at this time.
Figure 4-1. Front Panel Key Functions
