MANTIS ELITE
www.visioneng.com/support Mantis Elite with Universal Stand - User Guide
English
9
Desiccant Replacement
The desiccant removes excess moisture from the optical head.
Disconnect the power supply from the bottom of the head.
Remove the grommet covering the desiccant and remove the
desiccant.
Insert the new desiccant and replace the grommet.
LED Arrays
The method for removing the LED arrays is identical for either side.
Disconnect the power supply from the bottom of the head.
Loosen the two screws that secure the filter/array cover and
remove the cover.
Lift out the LED array and turn it over. Disconnect the array connector and
remove the LED array complete with filter
.
Reassembly is the reverse of this procedure.
Packing Contents
Assembly
1 Secure the universal mount to the work surface using
the G-clamp provided or by using appropriate
screws located in the counter bored holes of the
Mount.
2 Place the universal arm on top of the universal
mount. Lower onto spigot until fully mounted.
3 Loosen the upper retaining bolt on the universal arm. Remove
the lower retaining bolt
. Carefully place the Mantis viewing
head’s locating hook
over the upper retaining bolt of the universal
arm.
Replace the lower retaining bolt, ensuring the
bolt passes through the lower locating mount
of the Mantis viewing head.
Tighten the upper and lower retaining bolts then
re-seat the universal arm rubber gaiter
.
4 Fit the chosen objective lens into the
objective seat (ensuring the Vision logo is at the
front) and tighten the securing screw
. If
required, rotate the objective turret
and fit
another objective lens in the same way.
5 Ensuring the power adapter is suitable for your supply voltage, connect the power adapter plug to a suitable power
outlet and its output connector to the base of the universal arm.
6 Connect the output lead at the top of the universal arm to the rear of the viewing head.
Do not attempt to connect the power supply directly to the viewing head.
Universal mount
G-clamp
Counter balanced boom stand
Viewing head
Power adapter
Objective lens
Anti glare hood
Routine Maintenance
