Vision™ Installation Guide
2
Unitronics
Environmental Considerations
 Do not install in areas with: excessive or conductive dust, corrosive or flammable gas,
moisture or rain, excessive heat, regular impact shocks or excessive vibration, in
accordance with the standards given in the product’s technical specification sheet.
 Do not place in water or let water leak onto the unit.
 Do not allow debris to fall inside the unit during installation.
 Ventilation: 10mm space required between controller’s top/bottom edges & enclosure walls.
 Install at maximum distance from high-voltage cables and power equipment.
Mounting
Dimensions
Note that the Snap-in I/O module thickness is 23 mm (0.9”).

Vision V700-T20BJ Specifications

General

Brand	Vision
Model	V700-T20BJ
Category	Monitor
Language	English
