Visionis VIS-3003 - Sound and Light Indication

2
5. Wiring
No. Marks Color Description
1 BELL_A Pink Doorbell button
2 BELL_B Pink Doorbell button
3 D0 Green Wiegand output D0
4 D1 White Wiegand output D1
5 +12V Red Positive pole of power supply
6 GND Black Negative pole of power supply
7 OPEN Yellow Exit button
8 D_IN Brown Door contact
9 ALARM Gray Alarm Output
10 NO Blue Relay NO end
11 COM Purple Relay Com end
12 NC Orange Relay NC end
6. Sound and Light Indication
Operation
LED Color
Buzzer
Standby
Red flash
Press key
Di
Read card
Green
Di-
Door Open
Green
Di-
Operation Successful
Green
Di-
Operation Failed
Di Di Di
PIN Inputting
Red
Card&PIN Inputting
Red
Multi Card Reading
Red
Under Menu
Red
Under Setting
Orange
Manager Card Enter
Orange
Di Di
Manager Card Exit
Red Flash
Di-
Alarm
Red Quick Flash
Alarm
