EN
CHANGING THE REVERSIBLE DOOR
This appliance is designed with a reversible door feature. You have the option of configuring the door
to open/close either from the left or the right side. In order to reverse the opening direction of your
door, please follow these simple instructions. NOTE: If desired, please change the door swing
prior to installation.
CAUTION: To avoid personal injury to yourself and/or damage to property, it is highly
recommended that someone assist you during the door reversal process.
Door Removal
Turn off the unit and disconnect the power plug from the wall outlet.
Tilt the unit backwards and secure at an angle of 45 degrees.
Remove the upper hinge cover (Fig.1: No.6).
Remove the screws (Fig.1: No.1) that secure the upper hinge (Fig.1: No.5) to the frame. Remove
the upper hinge (Fig 1: No. 5).
Lift the door, remove from lower hinge and place it on a padded surface to prevent damage and
scratches.
Remove the screws (Fig 1: No.3) that hold the lower hinge, front leg and door stop (Fig.1: No.2).
Remove the lower hinge, front leg and door stop (Fig. 1: No.2).
Remove the front leg (Fig. 1: No. 4) and transfer to opposite side.
Remove the handle (Fig. 1: No. 8) and install to the opposite side of door. (See Changing the
Handle section on page 10).
Door Installation
Remove the cover plate (Fig. 2: No.7) covering the upper hinge holes.
Reverse the direction of lower hinge (Fig. 2: No. 2).
Install the lower hinge, front leg and door stop (Fig. 2: No. 2) on the lower frame with screws (Fig.
2: No. 3).
Secure door onto lower hinge.
Holding the door in the closed position, secure the upper hinge (Fig. 2: No. 5) to the door and
screw into the frame (Fig. 2: No. 1). Note: Do not fully tighten the screws (Fig. 2: No. 1) until the
top of the door is level with the top of the unit.
Install upper hinge cover (Fig. 2: No. 6) over the upper hinge.
