1" #9 HEX HEAD234X
Step 37
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Lift the bottom of the Roof Sheets to remove the Roof Installation
Tools, as shown on Side views.
2) Fasten the remaining screws of the Roof Sheets, with exception of
one as shown on Detail view.
33X
Side view
Side view
Detail view
2823 Foam Closure
Roof Sheet
To take off the Installation
tool, press it upwards with
your ngers.
7044 RS (Inside right)
Do not fasten these
two screws yet.
To Next Page
