10. Installation Instruction
10.1 Please refer to the following figure for the instrument screw assembly. Pay attention to the screw
tightening torque. Instrument damage caused by excessive torque is not covered by the warranty.
10.2 Clips are suitable for three handlebar sizes, 31.8mm, 25.4mm, and 22.2mm. Customers can choose
according to actual needs.
And 25.4mm and 22.2mm need to be matched with corresponding conversion.
M3*8mm
M4*12mm
Displayhostand
bracketuse
M4*8mm

ScrewInstallationDrawing
