Installation Montage
Installation Montage
SYSTEM SPECIFICATIONS
USE
§ User free operation in public places.
§ Hygiene.
§ Ability fort he handicapped people.
FEATURES
§ System Works with optical sensation (infrared beams) principle.
§ The main parts are the body, battery cover, solenoid valve group and panel mounted
electronic module.
§ System operates with 230 Volts main supply. Solenoid operates with 6 Volts.
§ Flow pressure of the system should be between 0,5 – 5,5 bars.
§ Cable connections are splash proof.
§ Transparent (polycarbonate) surface of the infrared module is durable against strokes. It is
also protected against damages during use by its small surface area.
§ Panels are made from stainless steel. (Durable, long-lasted, aesthetic)
§ Competeble with back inlet urinals (except the plastics water distributors)
§ Working range can be adjusted 40 to 80 cm
§ There is 5 seconds dedection delay to fitler the actions except for usage in front of the urinal.
§ Delay for flush after use 1 sec.
§ Flush volume can be adjusted from 1 – 5 lt.
§ Working range and flush time adjustment switches.
§ **Operating temperature between 5°C and 45°C**
WARNING
§ Do not use abrassive powder and asidic cleaning agents.
§ Clean with a moist clothing.
§ DO NOT WASH THE PANEL WITH HOSEPIPE SPRAY.
