FEATURES
4
11
11
2
3
4
1
5
6 7
9 10
8
60 cm models
Electrical insulation Class I
COOKING POINTS (Fig. 1.1)
1. Hi-light cooking zone Ø 140 mm
- 1200 W
2. Hi-light cooking zone Ø 210 mm
- 2300 W
3. Double hi-light cooking zone
Ø 210/120 mm - 2200/750 W
4. Hi-light cooking zone Ø 140 mm
- 1200 W
CONTROLS DESCRIPTION
5. Left front zone (1) control knob
6. Left rear zone (2) control knob
7. Right rear zone (3) control knob
8. Right front zone (4) control knob
9. Residual heat indicators
10. Power on indicator light
Electrical insulation Class I
COOKING POINTS (Fig. 1.2)
1. Hi-light cooking zone Ø 180 mm
- 1800 W
2. Hi-light cooking zone Ø 140 mm
- 1200 W
3. Hi-light cooking zone Ø 180 mm
- 1800 W
4. Hi-light cooking zone Ø 140 mm
- 1200 W
CONTROLS DESCRIPTION
5. Left front zone (1) control knob
6. Left rear zone (2) control knob
7. Right rear zone (3) control knob
8. Right front zone (4) control knob
9. Residual heat indicators
10. Power on indicator light
Fig. 1.1
5 6 7
9 10
8
2
3
4
1
Fig. 1.2
