8
HI-LIGHT DOUBLE ZONE and HI-LIGHT OVAL ZONES
The heating element is formed of a 2 coils of resistant material which reaches the work-
ing temperature quickly.
These zones are controlled by a continuous energy regulator switch (figs. 2.3a - 2.3b).
The heat intensity can be regulated continuously from “0” to “12” (max).
Check that the hob is clean and then switch on by turning the control knob.
When the hob is working, the pilot light will be on.
By switching on the second element (fig. 2.4), the surface area of the double and oval hi-
light zones can be extended.
For this purpose, turn the control knob (figs. 2.3a - 2.3b) fully to the right (position ).
Fig. 2.4
Second element
Hi-light
double
zone
Hi-light
oval double
zone
Fig. 2.3a
Fig. 2.3b
