VITROKITCHEN CB9060IB - Page 9

6. A 7-mm spanner shall be used in order to replace the injector. (figure 15)
7. Grill broiler doesn’t have a cover. There are screws that fix the grill broiler to the cavity, unscrew them by a
crosshead screwdriver.
Figure - 10
Figure - 11
Figure - 12
Figure - 13
Figure - 14
Figure - 15
