1.8 INSTALLATION REQUIREMENTS
DESCRIPTION UNITS
MR 620
MR 710
MR 730
MR 820
MR 840
MR 930
MR 1040
MR1130
Input Voltage V 3 x 400 (Supply tolerance +10%, -10%)
Frequency Hz 50/60
Start-Up power kVA
52
52
54
54
55
56
56
Slow Start-Up power kVA
44
44
44
44
44
44
44
Power required at setpoint
(depending on configuration, load and
setpoints)
kVA
8
8
9
9
10
11
11
Weight machine Air (maximum) kg/lb
2300 /
5071
2300 /
5071
2300 /
5071
2300 /
5071
2500 /
5522
2500 /
5522
2700 /
5952
2700 /
5952
Weight machine Nitrogen (maximum) kg/lb
2300 /
5071
2300 /
5071
2500 /
5522
2500 /
5522
2700 /
5952
2700 /
5952
2900 /
6393
2900 /
6393
Carrying capacity per leveling feet kg/lb
Nitrogen requirements minimum
(only for nitrogen machine)
bar/PSI 4.8 / 70
Nitrogen supply, maximum rate
m
3
/hr /
cfm
50 / 29.43
Nitrogen connection type ½” female NPT
Exhaust volume at single connection
Air Mode - No GRS
m
3
/hr /
cfm
450 / 265 at 300 Pa
Exhaust volume at single connection
Air Mode - GRS - Nitrogen
m
3
/hr /
cfm
200 / 118 at 100 Pa
Exhaust connection mm /
inch
165 / 6.50
Clearance for operate & maintenance
front,-, infeed,- and outfeedside
mm /
inch
120 /47.25
Clearance for operate & maintenance
backside
mm /
inch
150 / 59.05
