OPTION A: FIXING THE FRAME TO A SOLID WALL AND SUB FLOOR
Locate the wall fixing brackets,
oer them up behind the frame and
using a phillips screw driver, screw
the bolt into the bracket 2-3 full
rotations.
ii
Locate the wall fixing bolts. Measure
and cut the bolts using a hacksaw
5mm shorter than the total depth of
the wall void. Then clip the bolts into
the top frame adjustment holes.
i
Ensuring the brackets are upright,
mark on the wall the locations of
the holes to be drilled.
iii
Drill two 10mm holes where marked
on the sub-floor, and insert the
supplied raw plugs.
vi
Place the locking clips onto the
bolt, either side of the wall bracket
and tighten as follows:
A = against frame
B = against bracket
ix
Ensuring that the feet of the frame
are flush with the front edge of the
joists, mark on the sub-floor the
locations to be drilled.
iv
Remove frame and place to one
side. Drill two 10mm holes where
marked on the wall, and insert the
supplied raw plugs.
v
viii
To ensure the frame is plumb, adjust
the level of the frame using the
adjustment bolts.
Place the frame back between the
joists, and using a socket wrench or
spanner secure to the wall and floor
using the supplied screws.
vii
A B
-5mm
