Phase-coupler
Should there be no connectiopn between the receiver and the transmitter, check both sets within the same room, i.e. on the
same power circuit. If a connection is made you must assume that the different power circuits. In this case consult an electri-
cian and have a
VIVANCO
PK 1 phase-coupler installed. This phase coupler ensures that the two power circuits are connected
to one another, allowing for connection via several phases.
. .
Technical Data:
WI 2602 WI 2202
Modulation:
FM
channel a = 100
k?-iz
k
1
kHz
FM
Power connection:
220
V/50
Hz
Frequency:
115kHz+l
kHz
Loudspeaker/mike: low-Impedance
channel b = 115
kHz
& 1
kHz
130kHz+l
kHz
Weight:
approx. 660 g
channel c = 130
kHz
+
1
kHz
Dimension: 18 x
16
x
4,2
(BxLxH)
Output power HF:
approx.
3,5
mW
approx.
3,5
mW
DBP-tested:
G 400 302X TFW
Output power NF:
approx. 400 mW approx. 400 mW
)Subject to changes in the interests of technical
progressa
WI 2602
Operation elements
1.
2.
3.
4.
Power control lamp:
Lights up when the set is switched on.
Channel selection switch:
5.
6.
*
7.
,
Sliding switch to select channel. Two communicating stations must be set to the same channel.
Volume
control and ON/OFF switch:
Infinitely variable volume control and powe
switch.
Contlnous transmlsslon:
If the button is pressed the station concern
i
d transmits continously, e.g. for the supervision of babies or old people.
-
Only
with WI 2202. For WI 2602 see 7. rautomaticu.
Speak button:
By pressing the speak button contact can be made with the receiving statiofl. Important: You can only speak in one direction
at once. When the speak button is pressed reception is not possible. Free-hand speaking is possible only using the automatic
function (WI 2602 only).
Call bunon:
The call button sets off an electronic sound in the receiving station as long at it is pressed. It is not possible to speak while the
call button is being pressed.
Automatic:
The WI 2602 has an automatic button with an LED display. If this acoustically-controlled automatic switching funktion is se-
lected the station transmits only when ctecrly audible sound are picked up.
Warranty
The high quality standard and careful
checkings
of our products enable us to grant you full
guarantee
for
a
period of
1 (one) year
starting from date of purchase. Therefore please keep your voucher carefully. Further warranty according to the corresponding
terms of our sole agency in your country.
