External view, part, display
4
3 Display
Fig.4
Selects t he appropriate operating m ode.
Each time you press the button, a mode
is selecte d in a sequence that goes from
AU TO, COOL, DRY, FAN and HEAT(cooli ng
on ly models wit hout). The mode ind icator light
illuminates under the different mode settings
Fig.4.
MODE select button
Used to adjust (increasing/decre asing)
temperature setting s(1 C/2 F increments)
in a range of 17 C(62 F) to 30 C(88 F) o r
the TIMER setting i n a range of 0~24hrs ..
UP( ) and DOWN( ) button
NOTE: The control is capable of displaying
temperature in degrees Fahrenheit or degrees
Celsius. To convert from one to the other, press
and hold the Up a nd Down buttons at the same
time, for 3 seconds.
Used to initiate the AUTO ON start time and
AU TO OFF sto p time program, in conjucti on
with the & buttons.
TIMER button
Used to initiate the SL EEP operation.
SLEEP button
Power switc h on/off
POWER button
F
C
Con trol th e f an spe ed. P ress to select the fan
spe ed in t hr ee ste ps-LOW, M ED, a nd HI.
T he fa n spe ed in dicator lig ht illumina tes un de r
diff eren t fan setting s.
FAN button
S ho ws the se t te mp er ature in C
O
""
""
or
F a nd th e A uto -time r se ttin gs .
While on DRY and FAN modes, it shows
th e r oom te mp er atu re .
O
LED Display
Error codes:
E1-
E2-
P1-
Room temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call for service.
Evaporator temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call for service.
Bottom tray is full - Connect the
drain hose and drai n the collected
water awa y. If e rror re peats, call
fo r servi ce.
Remote signal receptor
(So m e m ode ls ha ve t h e
sig nal receptor on th e
fro nt panel , Fi g. 2 )
(The model has no
auto swing feature
withou t this button)
