NovoTouch User Manual
Copyright © 2017 Vivitek. Vivitek is a trademark of Delta Electronics, Inc. Page 12
Display Right View
The following illustration shows the right side of the display and its various components:
NOTE: The illustration shows the right side after installation of the VKA05 OPS module. See the
Installing the VKA05 OPS Module section for more information on how to install the OPS module.
Connects to the antenna included with the VKA05 OPS for Wi-Fi signal.
Lights up to indicate that the VKA05 OPS is powered.
Resets the VKA05 OPS module.
Connects to a USB flash drive to view media files or to a mouse/keyboard.
Reads media files stored on a microSD card.
Connects to a router for internet access.
Connects to either a second display or projector to duplicate or extend the
video shown on the display.
Connects to a USB flash drive to view media files or to a mouse/keyboard.
Connects to Blu-Ray/DVD players, set-top boxes, digital media players,
computers, or other video sources to broadcast video and audio.
Connects to Blu-Ray/DVD players, set-top boxes, digital media players,
computers, or other video sources to broadcast video and audio.
Connects to a computer to allow the touchscreen to control the computer’s
interface.
Connects to Blu-Ray/DVD players, set-top boxes, digital media players,
computers, or other video sources to broadcast video and audio.
Connects to a computer to broadcast video and audio.
Connects to the video source to broadcast its audio.
Connects to a computer to broadcast video.
Connects to a computer to allow the touchscreen to control the computer’s
interface.
Connects to a USB flash drive to view media files or to a mouse/keyboard.
